Beko Air Conditioners Error Codes List

See also: Beko Air Conditioners Service Manuals PDF

Beko air conditioners are equipped with an innovative self-diagnosis system. According to its results, when a malfunction is detected, the control device blocks the operation, reporting simultaneously its cause. The equipment reports defects in operation by flashing LEDs that light in a certain sequence, showing the number of the detected malfunction.

Beko air conditioner error detection can be dealt with without involving a service technician. To do this, you just need to know how the information embedded in the program by the manufacturer is decrypted. It should also be remembered that the system displays the DTC with high priority.

• improper unprofessional installation of a split system, carried out independently or by incompetent masters;
• non-compliance with the requirements for the operation of the unit;
• ignoring scheduled maintenance;
• normal wear of parts after prolonged use.

The equipment will shut itself off if:

• Secondary activation of the compressor does not occur within 3 minutes.
• If on top of the compressor the temperature exceeds 115 degrees. Normal operating temperature should not exceed 100 degrees.
• If the mains voltage drops below 175 or rises above 260 volts.
• If the inverter overheats due to the fact that a strong current or a higher voltage is applied to it.
• If the wires are open anywhere.
• If the fan operates more intensively than the norm or vice versa weaker (norm 300 - 400 rpm.).
• If 4 minutes the system does not receive messages about crossing through zero.

After that, the self-diagnosis system starts searching for defects and malfunctions and, having detected them, displays the desired error code on the display.

• E1 - error of the internal temperature sensor
• E2 - Evaporator Sensor Error
• E3 - error in engine operation
• E5 - switching error between indoor and outdoor unit
• 1E - error of the external temperature sensor
• 2E - capacitor sensor error

• F1 FF01 -
• F3 FF03 - high condensing temperature in cooling mode
• F4 FF04 - high condensation temperature in heating mode
• F6 FF06 - incorrect operation of the fan motor of the indoor unit
• F7 FF07 - error of the sensor of temperature of internal air
• F8 FF08 - Evaporator Temperature Sensor Malfunction
• F9 FF09 - condenser temperature sensor malfunction
