Error codes for Mitsubishi Electric air conditioners

P1

Temperature sensor malfunction TH3

P2

Sensor reading TH5 heat exchanger malfunction

R4

The drain pan is full above normal (CN4F float sensor may also malfunction)

Р5

Malfunction of a pump installed in the drainage compartment

R6

Incorrect execution of the command to lower or raise the temperature

P8

Incorrect temperature set in the heat exchanger.

R9

Malfunctioning sensor reading data from the TH2 heat exchanger

RA

The compressor was stopped and forced to stop.

E0

Cannot transmit signal to control panel

E1

The buttons on the remote control are faulty

E2

Addresses of internal systems are duplicated

E3

The address of the outdoor unit is incorrect

E4;

E5

The remote control signal receiver is faulty

E6

There is a short circuit in the connection of the indoor and outdoor unit

E7

Error transferring data in the system

E8

Open circuit near the data reception sensor

E9

Unable to contact transmitter

E0

Remote control battery low

EA

Incorrect installation of mains and wire connections

EB

Power Surge Protection

EC

Failed to start the system timer

ED

It is necessary to reset everything to the basic settings

EE

Unable to transfer data to the transmitter

EF

M-NET Error - Incorrect Wiring

U1

Sensor 63H indicates a pressure above normal (or a temperature above normal)

U1

Fatal error

U2

49C sensor indicates low pressure with air intake or low refrigerant

U2

The compressor runs at high temperature

U3

Capacitor varistor defective

U4

There is an open or short circuit in the power supply circuit of the outdoor temperature sensor

U5

Condenser temperature sensor signals excess

U6

Compressor current overload detected, device stopped

U7

49C sensor indicates an error

U8

Forced stop of the fan motor installed in the outdoor unit

U9; UH

Deviation from the norm of the voltage of the electric current coming from the network, an error in the readings of the voltage sensor

UA

Compressor start relay error

UD

Compressor overheated

UL

Low refrigerant pressure

UF

Voltage too high, compressor stop

UP

Power overload, forced compressor shutdown

Fb

Programming error

F1

No data from temperature sensor TH3

F2

Phase failure at L3

F3

Incorrect connection to internal control board - no signal

F4

Open connector

F7

The sequence in the loop phases is broken

F8

Unstable mains voltage

F9

No signal in connectors

FA

Phase failure in sections L2

E0

I can’t send a command to the air conditioner

Р1

Air intake data not read correctly

P2

Tubing failure

P3

System error

R4

No data from the Drain sensor

Р5

Mechanism overflow leakage

R6

Incorrect temperature reduction or increase

Р7

System error (data generation)

P8

Connection break

Transaction Status

Check for error code

LD1

Compressor

LD2

Temperature adjustment

LD3

Operation 63H3

LD4

The compressor operates during operation 63H2

LD5

Fan on

LD6

Four way valve working

LD7

Bypass valve

LD8

The crankcase heater is working

LED indication

Flash every 2 seconds

Faulty converter power, external power, thermistor, or outdoor unit control system

Two flashes every 2 seconds

Short circuit protection

Three flashes every 2 seconds

Protection against exceeding the normal temperature of the discharge system

Four flashes every 2 seconds

Thermistor over temperature protection

Five flashes every 2 seconds

System overpressure protection

Seven flashes every 2 seconds

Protection against accidental start of the system

Eight flashes every 2 seconds

Temperature error protection

One flash

Mains voltage decreased

Three flashes

Defrost triggered

Four flashes

High discharge system temperature

Five flashes

Outdoor thermistor

Seven flashes

Low discharge temperature

Eight flashes

The converter is protected

Nine flashes

Invert r checked
